600W 700W 800W 800 Watt 1000W Smart PV Mppt On Grid Tie Micro Inverter | Solardyna
This is the Solardyna brand micro inverter LDW – 800/1000 series, suitable for household solar systems, with 800W and 1000W power options. It supports WiFi communication, 5-year warranty, efficient MPPT tracking, high protection level, natural cooling, suitable for indoor and outdoor use, and can achieve intelligent monitoring and stable power generation.
Place of Origin
Guangdong, China
Model Number：DM-800
Input Voltage：4*MC4/25-55V
Output Voltage：120/230V
Output Current：5A/2.6A
Output Frequency：48-51 HZ
Size：220.5mm*183.8mm*44.3mm
Certificate：CEC CE VDE Rohs TUV
Warranty：1 year
Inverter type：On grid Solar Micro Inverter
Output parameters：120V/230V
Output voltage mode：120/230V Auto switch
Operating voltage range：25-55V
Temperature range：-20°C to +65°C
Waterproof grade：Ip65, IP67 waterproof could be ordered
MPPT efficience：99%
Communication：433/WiFi 5G
OEM：Accept OEM & ODM
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
Description
►Product Features
●Can Be Connected To Large Solar Systems
●Warranty 5 Years
●The Power Conversion Rate is 99%
●The Service lfe ls UP To 25 Years
●Waterproof grade:Ip65, IP67 waterproof could be ordered
●Output voltage mode 120/230V Auto switch
►Product Parameters
| Model | LDW-800 | LDW-1000 |
| Input Parameters (DC) | ||
| Recommended Solar Panel Ieput Power | 275-530Wx 2 | 275-530Wx2 |
| Number Of De Input Connections | MC4x2 | |
| Maximum Input Voltage | 60V | |
| De Voltage Input Range | 16-60V | |
| Starting Volage | 22V | |
| Maximum Power Point Tracking Voltage Range | 22-55V | |
| Mppt Tracking Accuracy | >99.5% | |
| Maximum Input Dc Current | 14A*2 | 16A*2 |
| Output Parameters (AC) | ||
| Maximum Output Power | 800W | 1000W |
| Rated Output Voltage | 230V | |
| Ac Voltage Range | 190-270V | |
| Maximum Output Current | 3.47A | 4.34A |
| Rated Output Frequency | 50Hz/60Hz | |
| Output Frequency Range | 47.5-50.5Hz/58.9-61.9Hz | |
| Harmonic Distortion | <5% | |
| Output Power Factor | >0.99 | |
| Maximum Conversion Efficiency | 96% | |
| Protection Level | Class I | |
| Protective Function | 8 Protections | |
| Operating Temperature Range | -40℃to+65℃ | |
| Indicator Light | Working status light+WIFI signal light | |
| Communication Mode | Wi-F1/2.4G | |
| Cooling Method | Natural cooling (no fan) | |
| Working Environment | Indoor/Outdoor | |
| Weights | 2.52kg | |
| Sizes(L*W*H) | 227mm*195.5mm*42mm | |
►Product Details
