Description

Mobile Solar Container Designed for Rapid Power Deployment

The 80kW mobile solar container is a fully integrated photovoltaic power system built inside a 20ft CSC-certified shipping container. Designed for rapid energy deployment, it arrives fully pre-wired with solar modules, mounting structure, string inverter and electrical panels already installed.

With a total solar array capacity of 92.16kWp, this containerized solar system delivers stable grid-connected or off-grid power without civil construction or complex on-site engineering. Simply position the container, unfold the solar arrays, and connect to the load.

92kWp High-Density Solar Array in a 20ft Container

This mobile solar container integrates:

• 192 solar modules (480W–520W range)
• Total capacity: 92.16kWp (90–105kWp configurable)
• 80kW string inverter
• Optimized 2×96 module bracket layout

When fully deployed, the system covers approximately 486㎡, achieving high energy density within a compact 20ft footprint. The engineered unfolding structure ensures mechanical stability and efficient solar exposure across six rows.

Wheel-Type Folding Structure for Fast Installation

The wheel-type solar unfolding mechanism allows smooth and controlled expansion of the panels, significantly reducing manual handling.

• Complete unfolding time: 110 minutes
• Complete folding time: 70 minutes
• Required personnel: 4
• Total system weight: 17 tons

In adverse weather conditions such as storms or hail, the array can be folded quickly to protect the modules and maintain system integrity.

This design makes it suitable for temporary, seasonal, or relocatable power applications.

Plug & Play Solar Container with Pre-Wired Electrical Integration

All electrical components are pre-installed and factory-tested before shipment, including:

• String inverter integration
• Internal cable routing
• Protection systems
• Electrical distribution panels

The plug & play configuration reduces commissioning time and eliminates the need for on-site structural assembly. This improves project timelines and lowers installation risk in remote environments.

Portable Solar Power for Remote and Industrial Applications

The 80kW mobile solar container supports multiple high-demand applications:

• Agriculture and water management systems
• Remote charging stations
• Construction and industrial sites
• Emergency and disaster recovery areas
• Events and temporary infrastructure
• Mining operations
• Military deployment
• Community and refugee energy support

Its relocatable structure allows the system to be transported and redeployed to different geographical locations as project needs change.

CSC-Certified 20ft Containerized Solar Power Plant

The system is built within a standard 20GP container compliant with CSC transport certification standards, ensuring:

• Structural durability
• International shipping compatibility
• Safe road and sea transportation
• Long-term environmental resistance

Container sizes available: 8ft, 10ft, 20ft, and 40ft configurations.

Technical Specifications – 80kW Mobile Solar Container

• Solar array capacity: 92.16kWp
• Inverter capacity: 80kW
• Container type: 20GP ×1
• Total unfolded footprint: approx. 103m × 2.38m × 0.8m structure layout
• Occupied area: 486㎡
• Total weight: 17 tons
• Installation personnel: 4
• Deployment time: 110 minutes

Frequently Asked Questions – 80kW Mobile Solar Container

1. How long does it take to deploy the 80kW mobile solar container?

The complete unfolding process takes approximately 110 minutes with a team of four people. The wheel-type expansion structure ensures smooth mechanical deployment without cranes or heavy lifting equipment. Folding can be completed in about 70 minutes, making it suitable for temporary or seasonal projects.

2. Is the mobile solar container suitable for off-grid and grid-connected use?

Yes. The 80kW mobile solar container can operate in both grid-connected and off-grid configurations. It integrates an 80kW string inverter and pre-installed electrical panels, allowing flexible system design depending on site requirements.

3. What is the total solar capacity inside the 20ft container?

The system integrates up to 92.16kWp of solar modules, with configurable module power ranges from 480W to 520W. This high-density layout maximizes power generation within a standard 20ft container footprint.

4. What area is required when the solar container is fully unfolded?

When fully deployed, the system occupies approximately 486 square meters. The engineered six-row layout ensures stable structural support while optimizing solar exposure.

5. Can the containerized solar system be relocated after installation?

Yes. The system is built inside a CSC-certified 20GP shipping container, allowing safe transportation by truck or sea freight. It can be redeployed to different geographic locations depending on project demand, making it ideal for mobile energy applications.

6. How does the system perform in harsh weather conditions?

The folding structure allows rapid retraction of the solar arrays in case of storms, hail, or extreme weather. Once folded, the modules are protected within the structural frame of the container, enhancing operational safety.

7. Does the mobile solar container require on-site engineering or civil construction?

No major civil works are required. The system is fully pre-wired and factory-tested before shipment. Installation mainly involves positioning the container, unfolding the modules, and completing electrical connections to the load or grid interface.

8. What applications is the 80kW mobile solar container designed for?

The system is widely used in agriculture and irrigation projects, construction sites, mining operations, emergency response areas, temporary events, remote charging stations, military deployment, and community electrification. Its rapid deployment and relocatable structure make it suitable for dynamic energy demands.
